Check 1: Check the power supply and connecting cable, please make sure to use a USB Type-C to C connecting cable that can pass 5A current and a power supply that complies with the PD protocol, or use a power adapter with a DC5525 connector to supply power to the device; (MHP50)
Check 2: Can the console enter DFU mode and read the USB drive after connecting to the computer? If yes, please try to update the firmware again.
Check 1: If the heater is used for the first time or stored in a humid environment, wait until the heater is sufficiently heated to maintain a constant temperature;
Check 2: Whether the hot plate has been installed;
Check 3: Whether the power cord is not firmly connected;
Check 1: Please check whether the power supply is connected and can be energised normally;
Check 2: Whether the power supply parameters are in accordance with the requirements for use;
Check 3: If the power parameters meet the requirements for use, the PD power limit (PD_PwrMax) can be adjusted at the menu as required. (MHP50)
Check 4: Try replacing the power supply with a higher power supply.
Check 1: Whether the hot plate has been installed;
Check 2: Whether the power cord is not firmly connected;
Check 1: Whether the "LowCur" menu option is set to "ON".
Note: When the "LowCur" menu option is on, the unit may still experience slight heating.
Check 1: Whether the machine is tilted;
Check 2: The anti-tilt setting (Tilt Angle) can be switched off in the menu, but needs to be reset after a power cut;
Check 3: Try updating the firmware to improve.
Check 1: The connected power supply does not support the PD power supply protocol, please replace it with a suitable power supply;
Check 2: The power cord used does not support the PD power supply protocol, please replace the power cord with a suitable one;
Check 3: Try updating the firmware again;
Check 4: Poor interface contact.
Check 1: Whether the soldering iron tip has been inserted or not;
Check 2: Replace another soldering iron tip to try whether it is normal.
Check 1: If the Bluetooth icon has been displayed on the station screen, the bluetooth communication may be blocked, please place the pen back to the station, disconnect the power supply of the base and re-power it up.
Check 1: Whether the soldering pen has been correctly placed on the control station, and whether the lightning charging icon appears in the status bar of the station screen;
Check 2: Whether the soldering pen is able to connect with computer to enter DFU mode? If yes, please complete the firmware upgrade and place it on the station again.
Check 1: Whether the soldering pen is able to connect with computer into DFU mode? If yes, please complete the firmware upgrade before connecting by Bluetooth again;
Check 2: Re-pair the soldering pen with the control station. Bluetooth pairing method is detailed in the manual 4.2;
Check 3: When the soldering pen's battery power is too low to make a Bluetooth connection, try allowing the soldering pen to be properly placed in the control station for charging or charging it separately for a few minutes before activating the Bluetooth connection.
Check 1: Has the soldering pen been Bluetooth paired with the control station? If not, please make a Bluetooth pairing connection first;
Check 2: Pull out the soldering pen and reposition it on the station.
Check 1: When the Intelligent Battery Management function is turned on, the screwdriver will intelligently judge the battery status and allow the battery to hibernate in the most suitable state to prolong the battery life. It is recommended to turn it on when the screwdriver needs to be stored for a longer period of time.
Check 2: For daily use, please switch off the battery management mode and observe whether the power consumption returns to normal.
Check 1: If the screwdriver become unresponsive after updating the firmware, please check whether the updated firmware is correct;
Check 2: Is the screwdriver able to connect to the computer to enter DFU mode? If yes, please try to update the firmware again.
Check 1: Check if the wrong firmware has been updated;
Check 2: Is the screwdriver able to connect to the computer to enter DFU mode? If yes, please try to update the firmware again.
Check 1: Temporarily close the anti-virus software or similar system enhancement software, replace the computer and data cable, and try to update the firmware again to see if it can operate normally;
Check 2: If it is a desktop computer, the console connection cable socket is recommended not to be plugged into the front panel socket of the chassis, but to be plugged into the socket at the rear of the chassis;
Check 3: Enter DFU mode and format the USB drive.
Check 1: Try updating the firmware.
Check 1: Whether it has been set to directional forward and reverse mode;
Check 2: Try updating the firmware.
When the torque reaches the highest torque shift, the screwdriver will stop for 3 seconds before working again, as to protect the screw and motor.
It may enter the mode only if you start the machine when the screwdriver is power off and connected with USB data cable.
Charging icon：
Fully charged icon：
When in low battery, a warning will appear on screen and the screwdriver will be automatically powered off: NO Power！
1、Turn off the external input power first, adjust the set power/current/voltage value down and then start the external input power;
2、Long press the MENU button of MDP-L1060 to enter the setting menu to adjust the corresponding setting value.
1、Please remove the peripheral covering of MDP-L1060 to ensure smooth ventilation;
2、MDP-L1060 internal fan will automatically run at maximum air speed, when the temperature drops to a safe temperature, the device will automatically return to normal use.
PRO XX.CSV in the USB memory drive is abnormal in the programming pull mode, please refer to the programming pull file example in 3.5 for modification or contact the after-sales service.
Check 1: Whether the working environment is more static electricity caused;
Check 2: Whether there are strong magnetic objects around;
Check 3: Please update to the latest firmware and try again.
Input is reversed, please connect the device correctly.
When the load consumes a large current, there will be a voltage drop on the connection line from the device under test to the load terminals, resulting in a large voltage deviation, so please use the XT30 Remote Compensation Interface to compensate for this.
Check 1: Whether the setting current value is lower than the rated current value of the current power supply, or the rated current value of the current power supply is too high.
Check 1: Currently powered devices accessed through the 2.5mm connector may cause internal abnormalities in the power supply, please access the power supply through the USB-C cable.
Check 1: Whether the working environment is more static electricity caused;
Check 2: Whether there are strong magnetic objects around;
Check 3: Please update to the latest firmware and try again.
To upgrade the firmware of oscilloscope, please carry out the operation below：
Ⅰ.Download the newest firmware appropriate to oscilloscope to your PC.
Ⅱ.Hold Pause button and turn on DS211 / DS212 / DS213, to enter DFU mode for upgrade.
Ⅲ.Use USB data cord to connect DS211 / DS212 / DS213 to your PC, and a removable hard disk named “DFU V3_xx_x” will appear on your PC. Copy the hex firmware to the root directory of that disk.
Ⅳ.After the extension of the firmware changes from “.hex” to “.rdy”,restart DS211 / DS212 / DS213. Then the upgrading process is finished.
Yes. Storage Inbuilt 8MB U disk storage for waveform data and images. Store file as BMP, BUF, or CSV format.
Yes. The Inbuilt Signal Generators are square wave, sine wave, triangular wave and sawtooth wave.
Yes. The firmware, source code and schematic will be provided. The materials can be found on http://www.minidso.com.
No. LA104 can display the traces with its built-in screen only.
The max voltage on channel 1-4 is +5V.
The max sample rate is 100Mhz for each channel when all 4 channels are enabled.
Yes, the modes of the wave are SPI, I2C, PWM.
The bandwidth of input channels is 100M.
