MHP30
MHP30

MHP30 Mini Hot Plate Preheater is an ultra-mini smart constant temperature hot plate with pocket size;

MHP30 has a small and exquisite appearance, with a square tower shape and a total height of only 5.2cm (2 inches);

It eliminates redundancy, retains sufficient effective heating area, greatly saves energy and heating time;

MHP30 controller and hot plate can be flexibly separated and replaced;The controller is equipped with an OLED display and two physical buttons (on the back);

A pair of support feet at the bottom can be spread out to better support the whole station;

The hot plate's heating body is made of brass with nano-ceramic coating, smooth on surface and evenly heated;

When using 65W PD power supply, it only takes 150 seconds to heat from 26°C room temperature to 300°C;

The controller has a built-in true color LED that changes color with the rises and falls of the temperature, letting you know the warm and cold at a glance;

MHP30 also has smart modes such as preset temperature, tilt protection, power wake-up and automatic sleep;

Users can set to turn on or off these functions according to their needs.

NHP30 (6).jpg




CONTENTS

MHP30 Controller ✖ 1

Hot Plate(BS30) ✖ 1

Type-C-C Cable ✖ 1

Safety Instructions ✖ 1


PACKING SPECIFICATIONS

Gross Weight:237g (including package)

Package Size:120mm ✖ 72mm ✖ 52mm


MAIN PARAMETERS
Power 60W (Max) Power Input PD Input
Temperature Stability ±3% Resistance to Ground <2Ω
Temperature Range 100°C~350°C(Max) Heating Area 30mm✖ 30mm
PRODUCT SPECIFICATIONS
Screen OLED Screen Product Size

Controller: L43mm✖ W35mm✖ H31mm

Hot Plate: L31mm✖ W31mm✖ H28mm

Power Interface USB Type-C-C Port Net Weight 82g (Control Part+ Hot Plate)
Certification Compliant with EU Certification CE FCC Data Transfer Interface USB Type-C-C Port
